High-Performance Linux-powered Mini PC with Dual Wi-Fi, USB 3.0, and S922X Chip

This Linux-based device is a high-performance solution powered by an Amlogic S905X3 processor, providing robust computing power for development, media, and industrial applications. Running Linux 5.15, it natively supports major distributions such as Debian, Ubuntu, and OpenWrt, making it ideal for developers and tech enthusiasts. With flexible hardware configurations (2GB/4GB RAM, 16GB–128GB ROM, and up to 256GB of expandable storage) and customizable features (real-time clock, dual Ethernet ports), it adapts to various application scenarios. Abundant interfaces (HDMI, Gigabit Ethernet, USB 3.0/2.0, etc.) and dual-band WiFi/Gigabit Ethernet ensure seamless connectivity. Leveraging Linux’s open-source, multi-user, and multitasking capabilities, this device is ideal for projects that require stability, customisation, and powerful processing.

Here’s a shorter version:

Linux-powered Mini PC: Powerful Processor and Customisation Options

  • Processor: Equipped with an Amlogic S905X3 processor (quad-core ARM Cortex-A55 CPU, maximum clock speed 1.98GHz, Mali-G31 MP2 GPU).
  • Linux System: Pre-installed with Linux 5.15 operating system, supporting Debian 10/11, Ubuntu 20.04/22.04, and OpenWrt distributions.
  • Hardware Configuration: Optional 2GB/4GB DDR3 memory, 16GB/32GB/64GB/128GB storage space, and supports storage expansion up to 256GB.
  • Interfaces: Equipped with an HDMI port, a Gigabit Ethernet port, USB 3.0/2.0 ports, a TF card slot, an optical fibre port, and an AV port (Android system only).
  • Network Connectivity: Supports dual-band Wi-Fi (2.4G and 5G) and Gigabit Ethernet, providing stable and fast network connectivity.
  • Customisation and Task Handling: Supports customizable features (real-time clock, dual Ethernet ports) and fully leverages Linux’s multi-user capabilities.
Click to consult

Description

Linux System and Core Specifications

This Linux-based device features an Amlogic S905X3 processor, the Linux 5.15 operating system, dual-band 2.4 GHz and 5 GHz WiFi, USB 3.0, and Gigabit Ethernet, providing powerful performance and rich connectivity.

Linux-powered Mini PC

Amlogic S905X3 Processor and Hardware Configuration

This Linux device is powered by an Amlogic S905X3 processor (quad-core Cortex-A55 CPU, Mali-G31 GPU), offering flexible RAM (2GB/4GB) and ROM (16GB-128GB) configurations to customise performance to your needs.

Linux-powered Mini PC

Linux 5.15 Device – Supports Debian 10/11, Ubuntu 20.04/22.04, OpenWrt

This Linux device runs Linux 5.15 and supports Debian, Ubuntu, and OpenWrt, ensuring compatibility with various software ecosystems and development workflows.



Linux-powered Mini PC

Linux Devices: Multi-User, Multi-Task – Open Source and Free Operating System

Discover the multi-user and multitasking capabilities of this free, open-source Linux system, ideal for development, media, and industrial applications.



Linux-powered Mini PC

Customizable Linux Devices – RTC, 1000M Ethernet, 4GB RAM, 256GB Storage

This Linux device offers a variety of customization options, including RTC, 100M/1000M Ethernet, up to 4GB of RAM, and 256GB of storage, to meet the specific needs of various projects.

Linux-powered Mini PC



Specification

Linux-powered Mini PC Specification

Product Model ZY2 Project Status M.P
CPU Chipset S922X
Architecture Quad core ARM Cortex-A73 and dual core ARM Cortex-A53 CPU
3D Graphics Processing Unit GPU ARM Mali-G52MP6(6EE) GPU
Graphical Program OpenGL ES 3.2, Vulkan 1.0 and OpenCL 2.0 support
RAM Capacity 4GB (LPDDR4)
ROM Capacity 32GB (16GB/64GB/128GB optional)
External storage USB Storage Devices Supported
Micro SD card Supported
Software
Operating system OS Version Ubuntu22.04(Linux5.15)
Debian10/11 OpenWrt(桌面服务版本lubuntu /xubuntu / lxde /  xfce4)
Language Multi-Language
Network service
Wi-Fi Type Support WiFi IEEE 802.11 a/ b / g / n / ac
Frequency Support 2.4G and 5G
Bluetooth Bluetooth Support BT 4.X
Interface
Charge DC connector   DC IN(12V/2A)
Video output HDMI   HDMI 2.1  4K*2K@60 max resolution  output
CVBS  Support  PAL/NTSC
Audio / 1* SPDIF
Micro SD External memory 1* TF card
USB port External memory 1* USB3.0
1* USB2.0
Ethernet Ethernet 1000M（100M optional）
Others RTC optional

Body Material ABS，cloth, Aluminum alloy
Color Ash
Size 106*106*21(mm)
Weight 0.194Kg
Cerifications(For Unit)
Standard CE /
RoHS /
Others Optional /
Package contents   Shipping Info
User manual *1 Gift Box Dimension(mm) 205*140*50(mm)
Gift Box *1 Carton Size(mm) 420*270*305 (mm）
Remote control *1 Qty Per Carton(pcs) 20
HD external cable *1 Gift Box.G.W(gs) 0.474KG
Power adapter *1 Export carton (G.W.)(kgs) 10.48KG
