| Item |
M10S |
Comments |
| MINI PC |
|
|
| series |
Intel Twin lake-N series processors |
|
| CPU |
Processor Type |
Intel Twin Lake N150 (Up to 3.6GHz) |
|
| Lithography |
Intel 7 |
|
| Cache |
6 MB Intel® Smart Cache |
|
| Processor Graphics |
Intel® Graphics |
Up to 1GHz |
|
| Memory |
Memory Types |
LPDDR5 |
|
| Memory size |
LPDDR5 12G 4800MHz |
optional 16G |
| Disk |
M.2 2280 |
1 (SATA / NVME PCIE3.0×2) Up to 4T |
|
| M.2 2280 |
3 (NVME PCIE3.0×2) Up to 4T |
|
| Wireless LAN |
WIFI |
Intel AX101 2.4G/5G,WiFi6 802.11ac/a/b/g/n/ax |
only support CNVIO, not support PCIE |
| Bluetooth |
BT5.2 |
|
| I/O |
USB3.2 |
3 |
GEN2 |
| LAN RJ45 |
2 (2500/1000M/100M/10M) |
i226 |
| HDMI2.0 |
2 (4K@ 60Hz) |
|
| USB-C |
1 (DP/DATA/PD) |
|
| Audio Jack |
1∮3.5mm、CTIA |
|
| PXE |
support |
YES |
|
| Hot Keys |
Power Button |
1 |
|
| Reset hole |
NO |
|
| FAN |
Smart Fan |
Support |
|
| Power |
Power input |
TYPE-C 12V/3A |
support PD |
| Physical Characteristics |
Dimension(LxWxH) |
146*97.5*32mm |
|
| Weight(g) |
≈352g |
|
| Software |
Support OS |
Window10 / window11 / ubuntu / Linux |
|
| |
WHQL/CTS |
|
|
